Eaton 93E UPS

Eaton 93E UPS
Eaton 93E UPS
Send Inquiry
Product Code : 38
Product Description

Eaton 93E UPS 15-500 kVA Technical Specifications :

Power

Ratings

15kVA/13.5kW, 20kVA/18kW, 30kVA/27kW, 40kVA/36kW, 60kVA/54kW, 80kVA/72kW, 100kVA/90kW, 120kVA/108kW, 160kVA/144kW, 200kVA/180kW, 300kVA/270kW, 400kVA/360kW, 500kVA/450kW

Topology

Double-conversion online UPS

Electrical Input

Nominal input voltage

400/230V, 4 wire (380/415V selectable)

Input voltage range

-15%, +20% from nominal (400V) at 100% load without depleting battery

Operating frequency

50/60 Hz (40 to 72 Hz)

Input power factor

>0.99 typical

Input current distortion

≤5% THD

Electrical Output

Nominal output voltage

400/230, 4 wire (380/415V selectable)

Output voltage regulation

+1% Static; +5% dynamic at 100% resistive load change, <20 ms response time

Battery

Battery

192 to 240 Cells (Continual selectable for 15-80kVA)
216/222/228/234/240 Cells (Selectable for 100-500kVA)

Charging method

ABM Cyclic Charging

General

Efficiency

> 98% High-efficiency mode (15-80kVA)
> 98.5% High-efficiency mode (100-300kVA)
> 99% High-efficiency mode (400-500kVA)
> 94% Double conversion mode (15-300kVA)
> 96% Double conversion mode (400-500kVA)

UPS bypass

Automatic on overload or UPS failure

Parallel technology

Powerware Hot Sync® Technology

Dimensions W x D x H

500 x 710 x 960 (mm) 15-20kVA (with internal battery)
500 x 710 x 1230 (mm) 30kVA (with internal battery)
500 x 710 x 1500 (mm) 40kVA (with internal battery)
600 x 800 x 1876 (mm) 60-200kVA
1600 x 820 x 1880 (mm) 300/400/500kVA

Cabinet rating

IP20 with standard washable dust filters

Weights without internal battery

15/20kVA-72kg, 30kVA-88kg, 40kVA-120kg,
60kVA-202kg, 80kVA-245kg, 100kVA-283kg,
120kVA-311kg, 160/200kVA-457kg,
300kVA-860kg, 400kVA-970kg, 500kVA-1020kg

Weights with internal battery

15/20kVA-272kg, 30kVA-376kg, 40kVA-490kg

Overload

150% for 1 minute, 125% for 10 minutes, >150% for 150ms

Communications

Display

Graphical LCD with blue backlight

LEDs

(4) LEDs for notice and alarm

Audible alarms

Yes

Communication ports

(1) RS-232, (1) USB, (1) EPO

Communication slots

(2) Mini-slot communication bays

Environmental

Operating temperature

0oC to +40oC
Batteries recommended max. +25ºC

Storage temperature

-25oC to +55oC without batteries
+15oC to +25oC with batteries

Relative humidity

5–95%, non-condensing

Audible noise

15-20kVA<55 dBA at 1m typical
30-40kVA <62 dBA at 1m typical
60-120kVA <65 dBA at 1m typical
160-200kVA <70 dBA at 1m typical
300-400kVA <73 dBA at 1m typical
400-500kVA ≤75 dBA at 1m typical

Altitude

<1000m at +40°C

Certifications

EMI standards

EN55022/EN55024

EMC compliance

IEC 62040-2

Quality

ISO 9001: 2000 and ISO 14001:1996

Communication Accessories

Network-MS

Web/SNMP Card

Modbus-MS

Web/SNMP and Modbus Card

Relay-MS

Relay (Dry Contact) Card -DB9 Connection

Industrial Relay

Relay (Dry Contact) Card -Terminal Connection

116750224-001

Environmental Monitor Probe (EMP) kit (need to plug into Web/SNMP Card or Web/SNMP and Modbus Card to work)

System Accessories

Battery Cabinets & Battery Circuit Breakers (60-200kVA)
Maintenance Bypass Switches (MBS) (100-200kVA, standard on 15-80kVA)
Top Cable Entry (60-200kVA, standard on 300-500kVA)
System Parallel Modules (60-200kVA)
Dual input kit (15-80kVA)
IP21 hood (15-200kVA)
Rear Chimney (60-200kVA)

In the interests of continuous product improvement all specifications are subject to change without notice.
