Cummins 140 kVA Three Phase Silent Diesel Generator

About Cummins 140 kVA Three Phase Silent Diesel Generator

Cummins 140 kVA Three Phase Silent Diesel Generator Brand Cummins Model Name/Number C140D5P Aspiration Turbocharged Current 195A Exhaust Temperature 496 Deg C Displacement 5.88 Litre Mean Piston Speed 6 m/s Starting System 24 V DC Electrical Total Coolant Capacity 25.6 Litre Compression Ratio 16.5/1 Exhaust Pipe Size 4 inch Enclosure IP 23 Stator Winding Double layer lap Duty Prime Power Rating 140/112 kVA / kWe No of Phases 3 Output Voltage and Frequency 415 V,50 Hz Power Factor 0.8 (lagging) Engine Model QSB5.9-G1 MoEF Certified Power 184 (bhp) Required Power for Rated kVA 175 (bhp) Cooling Liquid Cooled (EG Compleat 50/50) No of cylinders 6,In-line Bore x Stroke 102 x 120 mm Fuel High Speed Diesel Fuel consumption 25.92 (litre/hr) @75% load with radiator and fan & 31.91 (litre/hr) @100% load with radiator and fan Performance class of generator set ISO 8528-5 G2 Lube oil specification CI4+ 15W40 Lube oil sump capacity or High Low level 14.2- 12.3 Litre Total lubrication system capacity 15.7 Litre Total Wet Weight 552 Kg (Engine+Radiator) Engine Length x Width x Height 1066 x 642 x 1029 mm Combustion Air Intake 382 cfm @100% load (+/-5%) Alternator Make Stamford (CGT) Alternator Frame UCI274E Voltage Regulation +/- 1% Max Class of Insulation H Class Winding Pitch 2/3 Pitch Rotor Dynamically Balanced Waveform distortion or Total Harmonic Distortion No load less than 1.5 %,Non distorting balanced linear load less than 5 % Maximum Unbalanced Load across phases Less than or equal to 25% Telephonic Harmonic factor Less than 2% We are offeringCummins 140 kVAThree PhaseSilent Diesel Generatorto our customers.
